Wiltronics Electronics Testing Equipment and Their Types

November 11, 2020

Testing Equipment Collage - Oscilloscope, multimeters, galvanometer and logic probe

Electronic test and testing equipment is a key component to any electronics-related production, development and maintenance activity. From digital multimeters to testing accessories, they do an excellent job when it comes to detecting faults and peculiar function in devices.

Whether you’re setting up your own electronics lab or you just enjoy taking items apart and want to understand how electronics or devices work, owning testing equipment can be to your great advantage.

To help you find the right electronics testing equipment for you, why not browse our extensive range of electronics test devices below? From multimeters, digital capacitance testers to signal and waveform devices and student bench equipment—we have everything you need to help you find and analyze the circuit conditions and maintenance requirements in various equipment.

Capacitance Meter

Testing Equipment: Capacitance Meter

A capacitance meter is electronic test equipment used by both amateurs and professionals to measure a capacitor. If you’re looking for one, you might want to check out our available unit below.

This Tenma 72-8150 Digital Capacitance Meter (ME3173) has 3½ digits and is extremely robust and reliable. It can measure resistance, transistor hFE and test diodes.

This capacitance meter can also test continuity with an audible buzzer and has a broad capacitance measurement range and precise accuracy. You can use it to measure the circuit designed capacitance of the cable, switch and PCB layout.

This model also features the following:

  • Easy to use
  • Low battery indicator
  • Wide range
  • Dual integration A/D converter
  • Rotary switch for function selection
  • Overload fuse protection
  • Includes alligator test clips
  • Direct insert jacks
  • Includes battery, alligator clips & user manual

Testing Equipment: Multimeters and Accessories

Multimeters, also known as Volt-Ohm-Milliammeters (VOM), are definitely some must-have equipment for your toolbox. This tool is designed to measure basic circuit properties, such as voltage and resistance.

There will be times when your circuits stop working due to faulty wires. With the help of a multimeter, you can check the connections and save a lot of time. It really does come in handy when troubleshooting electrical connection and circuit issues.

Digital Multimeter Low Cost

1. Digital Multimeter Low Cost

This low-cost digital multimeter (ME3080) is easy to use and features an LCD display and compact design. The diode test measures the forward resistance of a semiconductor junction at test current 1.5mA max.

This product also features the following:

  • 3½ Digit 12.5mm High LCD Display
  • Compact design
  • Transistor, diode test
  • 10A DC range
  • CE certified

Analogue Multimeter

2. Analogue Meter

The Digital multimeter has almost completely taken over, but there are some who still prefer to use a analogue meter (ME3022). This well-made meter has audible continuity, in addition to the normal set of functions.

This multimeter unit also features the following:

  • 10 Amp DC, 20,000 ohms/V DC
  • Mirrored large meter face
  • Transistor Test
  • Continuity Buzzer
  • Fused & Diode Protected
  • Diode Test

Digital Auto Range Multimeter

3. Digital Auto Range Multimeter

This Auto Range Digital Multimeter (ME3083A) is ideal for both students and handymen. This model features a large LCD display, full-function protection and Auto power off, just to name a few.

Great value for what you are getting! This auto range multimeter is also designed with:

  • Autoranging
  • True RMS
  • Auto power off when there is no measurement in 15 minutes
  • Backlight display
  • NCV Non-contact voltage detection
  • Data hold function
  • Strong antimagnetic and anti-interferential performance

5 in 1 Sensor Environmental Digital Multimeter

4. 5 in 1 Sensor Environmental Digital Multimeter

This Multifunction Digital Multimeter (ME38210) is excellent for measuring environmental conditions, such as sound & light levels, indoor humidity and temperature.

It’s also ideal in server rooms, construction sites, factories, laboratories, greenhouse/hydroponics, archive & storage areas, and anywhere environmental conditions need to be considered. Take light readings of various spaces and compare them to the recommended levels listed in the manual.

The multimeter also features non-contact voltage detection, and measures both AC & DC voltage and current.

Signal & Waveform Testing Equipment

Also known as a Function Generator, a waveform generator is a testing device that is used for generating Sine, Square, Triangular and Sawtooth waveforms. This equipment produces a variety of different waveforms at the desired frequency.

Check out below our on-hand Signal & Waveform Test Equipment.
CRO Oscilloscope 25MHz

1. Digital Oscilloscope

Featuring a 7-inch LCD, this dual-channel digital Oscilloscope (ME4431C) is designed to meet the requirements of professional electronic engineers. It also features powered digital signal processing paired with great functionality and logical display-control panels.

This easy to use intuitive device also features the following:

  • Screensaver function
  • Trigger modes: Edge, Pulse, Video, Slope, Alternative, and Delay
  • Front and back USB ports
  • Unique digital filter function and waveform recorder function
  • Pass/Fail function
  • Auto measure function
  • Cursor measure covers Manual, Track and Auto modes
  • Channel waveform and its FFT waveform displayed on split-screen

Function Generator

2. Function Generator

This unit combines a 0.2Hz, 3MHz function generator (ME4510B) and independent 6 digit frequency counter with a frequency range from 1.0Hz to15MHz. The counter will display the output frequency of the generator or can be switched to work as an independent frequency counter.

Logic Probe
This quality Logic Probe (ME4210) will test all logic families, such as TTL, LS, CMOS, etc. Pulse/normal switches are attached to indicate pulse or continuous signals.

Plus, three LEDs provide the logic level indication.

Galvanometer +/- 50uA

Testing Equipment: Student Bench Meters

These Bench Meters are available in single, dual, and triple range versions, in a variety of measurement ranges.

We also have a range of 4mm banana plug leads. For the cost of the two stacking plugs you can now have a pre-made lead!

Available in red, black, blue, green and yellow. Lengths of 100mm, 250mm, 500mm and 1000mm are available in a super flexible 0.75mm² cable.
